Broadband Opto-Electrical Receivers in Standard CMOS starts from the basic fundamentals necessary for the design of opto-electronic interface circuits. The book continues with an in-depth analysis of the photodiode, transimpedance amplifier (TIA) and limiting amplifier (LA). To thoroughly understand the light detection mechanisms in silicon, first a one-dimensional and second a two-dimensional model is developed. Analytical design equations are derived to guide the design of the amplifying circuits. For the TIA, the focus is on the sensitivity-speed trade-off. For the LA, a high gain-bandwidth is pursued. Several practical design examples reveal the subtleties and challenges encountered during the design of high-performance analog circuits. Broadband Opto-Electrical Receivers in Standard CMOS covers the total design flow of monolithic CMOS optical receivers. All material is experimentally verified with several CMOS implementations, with ultimately a fully integrated Gbit/s optical receiver front-end including photodiode, TIA and LA.
| Autorius: | Michiel Steyaert, Carolien Hermans, |
| Serija: | Analog Circuits and Signal Processing |
| Leidėjas: | Springer Netherlands |
| Išleidimo metai: | 2010 |
| Knygos puslapių skaičius: | 196 |
| ISBN-10: | 9048175720 |
| ISBN-13: | 9789048175727 |
| Formatas: | Knyga minkštu viršeliu |
| Kalba: | Anglų |
| Žanras: | Laser physics |
